Cluster Casing

Cluster Casing

Item Image Description Chapter Qty Select Qty Price Add to Basket
1
Assembled Cluster housing

A9017017

€3338.69 €4106.59
2
D105 outer race

P9017005

€204.91 €252.04
3
Bearing core

P9017012

€6.30 €7.75
4
round bolt

512800032

€0.38 €0.47
5
Reverse idler axle

P9002103

€44.69 €54.97
7
Ball bearing

101000005

€27.29 €33.57
8
Double lip seal - Ø20x30x7

514500002

€6.29 €7.74
9
M10-150 insert thread

213000003

€21.61 €26.58
10
Double lip seal - 32x45x7

514600001

€23.05 €28.35
11
K expander plug

519212014

€9.30 €11.44
12
Bearing

102000001

€3.87 €4.76
13
Lip Seal D110

514920002

1

€23.53 €28.94
14
Needle bearing

101500004

€168.50 €207.26
15
SIDE WASHER

P9017042

€32.17 €39.57
16
M8-100 insert thread

212000028

€0.84 €1.03
17
Oil protector

P9017052

€21.96 €27.01
18
CHC bolt M4-10 cl.8.8

512004010E

€0.13 €0.16
20
BS seal D4

514920004

€0.84 €1.03
21
M6-100 insert thread

212000004

€0.63 €0.77
View full details

Documentation is available to authorised customers only. Please request by contacting Race & Rally by phone, email or online chat. Thanks.
