Regular price
€135.58
€166.76
63.4mm
63.2mm
14.4mm
47.8mm
Compound Information
Compound Information
DS2500 (H)
These are the amongst the foremost high performance track day pads in the business
Main Applications:
- Track Day
- Light race use
- Rear GT
- Rear rally
- Front Hillclimb
- Low heat events
Main Features:
- Road style refinement but with race material ability to withstand heat with respect to life and friction coefficent.
- Average friction coefficient of 0.41 over working temperature range of 0°C to 500°C
WARNING:
DS2500 does not have R90 certification and so it is not recommended for road use in those countries which require R90.
DS2500 Friction Coefficient (MU) Versus Temperature (°C)
Optimal operating temperature
Relative performance characteristics under heavy-duty race conditions
Suggested applications
Low stock
Brake Pad Dimensions:
| Manufacturer | Ferodo |
| Part Number | FCP810H |
| Pad Width | 63.4mm |
| Pad Height | 63.2mm |
| Radial Depth | 47.8mm |
| Thickness | 14.4mm |
| Compound | (H) DS2500 |
| Barcode | 5016687210378 |
Brake Pad Compound Information:
DS2500 (H)
These are the amongst the foremost high performance track day pads in the business
Main Applications:
- Track Day
- Light race use
- Rear GT
- Rear rally
- Front Hillclimb
- Low heat events
Main Features:
- Road style refinement but with race material ability to withstand heat with respect to life and friction coefficent.
- Average friction coefficient of 0.41 over working temperature range of 0°C to 500°C
WARNING:
DS2500 does not have R90 certification and so it is not recommended for road use in those countries which require R90.
DS2500 Friction Coefficient (MU) Versus Temperature (°C)
Optimal operating temperature
Relative performance characteristics under heavy-duty race conditions
Suggested applications
Cross References:
| Carbon Lorraine | 5002W48 |
| Ferodo Racing | FCP810 |
| Mintex | MGB535 |
| Performance Friction | 0051 |
Ferodo Racing - Pad Bedding.pdf
