The best alternative in terms of performance and reliability to the original Bosch 0580254044 currently on the market.

TECHNICAL SPECIFICATIONS:

• Female Outlet: M12x1.5 Banjo - One way valve stub
• Female Intet: M18x1.5
• Pump: P3044.1
• Voltage: 12V DC
• Max Flow rate: 378 Ltr/Hr
• Flow rate @ 3 Bar (44psi): 318 Ltr/Hr
• Flow rate @ 5 Bar (73psi): 258 Ltr/Hr
• Max Pressure: 10.4 BAR
• Location to Tank: 0.6 Metres
• Length: 194mm
• Diameter: 60mm
• Weight: 1.03 Kg

**Note: Please ensure that a pre-filter such as our Bullet Filter, is fitted prior to installation to prevent contamination.

Inlet Adaptors:

• Dash 6 to M18 x 1.5 - 306-06-M18
• Dash 8 to M18 x 1.5 - 306-08-M18

DOWNLOADS:

Hi OTP044 Flow Chart

CROSS REFERENCE

• Bosch - 0580254044
• ATL - PU-AB-030
• HI - HP3044.1
