TECHNICAL SPECIFICATIONS:

• Bore Size: 5/8"
• Thread Size: 5/8" x 18
• Ball Width: 19.05mm | 3/4" | 0.750"
• Body Head Width: 14.656mm | 9/16" | 0.577"
• Body Head Diameter: 38.735mm | 1.17/32" | 1.525"
• Thread Length: 39.675mm | 1.9/16" | 1.562"
• End of Thread to Centre of Bearing: 66.68mm | 2.5/8" | 2.625"
• Misalignment Angle: 12°
• Ultimate Radial Static Load Capacity: 25,909 lbs
• Material: Carbon Steel
• Body - 4340 Steel, heat-treated, protective coated for corrosion resistance.
• Race - 17-4PH Stainless Steel, heat-treated
• Ball - Alloy Steel, heat-treated and hard chrome plated.
• Bearing Type: Rod-end
• Handedness: Left-hand Thread
• Lubrication Type: PTFE (Polytetrafluoroethylene) Lined
