TECHNICAL SPECIFICATIONS:

• Internal Diameter: 19.05mm | 3/4" | 0.750"
• Outside Diameter: 34.925mm | 1.3/8" | 1.375"
• BW (Bearing Ball Height): 22.225mm | 7/8" | 0.875"
• HW (Bearing Sleeve Height): 16.002mm | 0.630"

• Misalignment Angle: 13°
• Material:
• Race - 17-4PH Stainless Steel PTFE Lined
• Ball - 440C Stainless Steel
• Bearing Type: Spherical
• Lubrication Type: PTFE (Polytetrafluoroethylene) Lined
• Retention Method: Circlip / Snap-ring
• Radial Static Limit Load: 37,000 lbs
• Axial Static Limit Load Capacity: 7,730 lb
