CP5219 - 4 Piston Caliper - Two Piece Billet

SKU:CP5219-16S0

€1313.65 €1615.79

Sale Sold out

Ultimate Caliper for 13" wheels

Piston Size Ø34.9mm x2 | Ø41.3mm x2

Caliper Hand Right Hand Trailing Left Hand Trailing Right Hand Leading Left Hand Leading

Quantity

Out of stock, contact for leadtime

View full details

CP5219 - 4 Piston Caliper - Two Piece Billet

Applications:

Front & Rear for 13" wheel
Lightweight Sportscar

Features:

Radial Mount, 152 x 42.78mm centres
Two piece billet aluminium alloy body
Suits Ø280 x 25.4mm disc
High Grade Aluminium pistons
CNC machined from billet
Superior dynamic performance than that of CP4219
Stainless Steel wear plates

Part Numbers:

Right-hand Trailing - CP5219-16S0
Left-hand Trailing - CP5219-17S0
Right-hand Leading - CP5219-18S0
Left-hand Leading - CP5219-19S0

Technical Specifications:

Piston Sizes	Ø34.9mm x2 Ø41.3mm x2
Piston Area	45.92 cm²
Disc Diameter	Max - Ø280.0mm
Disc Thickness	25.4mm
Weight (no pads)	1.98 Kg
Hydraulic Threads	M10 x 1.0
Mounting Type	Radial
Mounting Centres	152.00mm
Mounting Offset	42.78mm
Mounting Hole	Ø10.27mm
'PL' Dimension	56.81mm
Bleed Screw Tightening Torque	17Nm

Spare Parts

Pistons	Ø34.9mm - CP2876-101 Ø41.3mm - CP2270-92
Seal Repair Kit	CP4518-GK
Pad Retainer Tube	CP4219-122
Pad Retainer Bolt	CP5100-126
Wear Plates	CP4219-7
Bleed Screw	CP3880-1
Bleed Screw Cap	CP2494-177
Fluid Pipe	CP5219-6

Brake Pads

Pad Shape	CP3215D42
Pad Area	51.7cm²
Pad Depth	42.0mm
Thickness	16.8mm

CP5219 - Customer Drawing.pdf

Option	SKU	Barcode
Brand	AP Racing
Ø34.9mm x2 \| Ø41.3mm x2 / Right Hand Trailing	CP5219-16S0
Ø34.9mm x2 \| Ø41.3mm x2 / Left Hand Trailing	CP5219-17S0
Ø34.9mm x2 \| Ø41.3mm x2 / Right Hand Leading	CP5219-18S0
Ø34.9mm x2 \| Ø41.3mm x2 / Left Hand Leading	CP5219-19S0
