TECHNICAL SPECIFICATION:

• Internal Diameter: .750″ (19,05 mm)
• Outside diameter (OD): 1.5625″ (39,69 mm)
• Ball width (BW): 1.280″ (32,51 mm)
• Race width (RW): .620″ (15,75 mm)
• Ball diameter: 1.375″ (34,93 mm)
• Shoulder diameter: .950″ (24,13 mm)
• Misalignment α: 18°
• Fit / no load breakaway torque: 4-10 In-Lbs
• Maximum static radial load: 57108 lbs (254016 N)
• Maximum dynamic radial load: 24200 lbs (107642 N)
• Approximate weight: .32 lbs (143 g)
• Material
  1. Ball: CRES 440C stainless steel, heat treated
  2. Race: 17-4 PH stainless steel, heat treated
  3. PTFE liner: Rose ‘D’ Type Enhanced in accordance with SAE-AS81820
• Maximum operating temperature: 180° C (356° F)

• Manufacturer: NMB
