Facet 476459 Silver Top Competition Cylindrical Fuel Pump - STC505

An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.

Technical Specifications:

• Specification: Fast Road
• Pump:  476459E
• Voltage: 12v
• Earth: Neg
• Pressure (PSI): 6.0-7.0
• Flow: US Gallons/Hr 35
• Dry Prime Height: 0.6 Mtrs
• Thread Size: 1/8th NPTF
• Operating Temperature: -40º to +180° F (all Models)
• Average Run Time or MTBF: 6000 hrs
• Legal Requirements: Certified & Complies With EEC 95/54 Requirements
• Length: 140mm
• Diameter: 54mm
• Weight: 0.7kg
• Please Note: Designed and manufactured to automotive specification and not recommended for the maintenance of flight
• Applications: Motorsport, Marine

Cross Reference:

• HP3190
• 30-00106
• 170351C1
• 170352C1
• AR65058
