JC40 Sausage Megaflow Filter

SKU:JC40-S-25

€195.50 €240.47

Sale Sold out

Internal Height 25mm 40mm 65mm 100mm 125mm

Frame Colour: Red

Quantity

Out of stock, expected in 3-5 days from order

View full details

JC40 Big Twin Carburettor Sausage Filter

These robust filters are the standard fit for most competition cars around the world. The sausage version is used where the standard box shaped filter will not fit within the available space.

ITG use a three-layer "Trifoam' system, with the outer two layers of foam providing optimum filtration and load-up capacity whilst the inner layer is made from special self-extinguishing foam. These three layers combined give the very best air flow, engine protection and safety.

The ITG JC40 Sausage Air Filters are available in differing heights to help fitment for your application. ITG recommend fitting the tallest element possible, though a gap of 13mm (1/2") average must be left over the top of the filter for air to circulate. When using Ram pipes, there must be an absolute minimum gap of 19mm (3/4"), but preferably around 32mm (1 1/4") between the end of the ram pipe and the underside of the top of the filter.

Please select your required Air Filter internal height from the drop down menu above.

Specifications:

QTY of 1/4 Turn Fasteners: 1
Please Note: ITG air filters require pre-oiling prior to installation
Trim Colour options:
- Red
- Black

Measurements

A - (Internal Height, mm) Distance from face of baseplate and the inside face of the filter
B - (Width, mm) External width of the filter not including the lug
C - (Length, mm) External length of the filter.
D - (Overall Height, mm) Overall external height of the filter

JC20 Sausage Megaflow Filter Size Options

Part No.	A (Internal height)	B (Width)	C (Length)	D (Overall height)
JC40/S/25	25	142	379	50
JC40/S/40	40	142	379	65
JC40/S/65	65	142	379	90
JC40/S/100	100	142	379	125
JC40/S/125	125	142	379	150

Option	SKU	Barcode
Brand	ITG
25mm / Red	JC40-S-25
25mm / Black	JC40-S-25B
40mm / Red	JC40-S-40
40mm / Black	JC40-S-40B
65mm / Red	JC40-S-65
65mm / Black	JC40-S-65B
100mm / Red	JC40-S-100
100mm / Black	JC40-S-100B
125mm / Red	JC40-S-125
125mm / Black	JC40-S-125B
