Ø300mm x 25.4mm Ventilated Brake Disc - 12 x 196.2mm PCD

Ø300mm x 25.4mm Ventilated Brake Disc - 12 x 196.2mm PCD

CP4348-910P

€306.88 €377.46
Sale Sold out

Brake Disc Dimensions

  • Outside Diameter: 300mm
  • Thickness: 25.4mm
  • Mounting P.C.D.:
  • 196.2mm
  • Mounting Type: Bolted - 12 Bolt
  • Eye Diameter: 213.3mm
  • Inside Flange Diameter: 181.5mm
  • Mounting Flange Thickness: 6.67mm
  • Max Pad Depth: 42.0mm
  • No. of Vanes: 48
  • Air Gap: 9.0mm
View full details

Brake Disc Specifications:

 Outside Diameter Ø300mm
Thickness 25.4mm
P.C.D. 196.2mm
Fixing Type Bolted - 12 Bolt
Eye Diameter 213.3mm
Inside Flange Diameter 181.5mm
Mounting Flange Thickness 6.67mm
Max Pad Depth D42
No. of Vanes 48
Air Gap 9.0mm
Weight (Kg) 4.6
Face Types Available P
Notes

Brand:

AP Racing

Manufacturer Part Number:

CP4348-910P, CP4348-911P
