CP7373 - Ø184mm Triple Plate - Sintered Paddle Clutch

CP7373 - Ø184mm Triple Plate - Sintered Paddle Clutch

CP7373-NE90-SF

€858.00 €1055.34
Sale Sold out
Flywheel Fixing
Torque Capacity
Material
View Docs
View full details

CP7373 - Ø184mm Triple Plate Sintered Paddle Clutch

Typical Applications:

  • Race
  • High powered engines

Features:

  • Push Type
  • Triple plate
  • Stepped Flywheel Fixing
    • Inner diameter location.
  • 6 bolt, one piece cover and lugs
    • machined from aluminium alloy. Allows dust and debris to escape.
  • Suitable for engine speeds of 10,000 rpm
  • Black hard anodised
  • Stainless steel wear plates fitted
  • Individually tested
    • match machined, balanced and clutch load recorded.
  • Mounting studs available - CP4702.

Part Numbers:

  • CP7373-CE90-SF
  • CP7373-OE90-SF
  • CP7373-NE90-SF

Technical Specifications:

 Torque Capacity - Nm (lbs/ft)
  • CP7373-CE90-SF - 1271 (938)
  • CP7373-OE90-SF - 798 (588)
  • CP7373-NE90-SF - 491 (362)
Release Load - Max Peak New - daN
  • CP7373-CE90-SF - 350
  • CP7373-OE90-SF - 240
  • CP7373-NE90-SF - 160
Release Load - Max Peak Worn - daN
  • CP7373-CE90-SF - 440
  • CP7373-OE90-SF - 330
  • CP7373-NE90-SF - 220
Set-up Height - New
  • CP7373-CE90-SF - 36.18 / 32.94mm
  • CP7373-OE90-SF - 36.97 - 33.70mm
  • CP7373-NE90-SF - 36.16 / 32.90mm
Set-up Height - Max Worn
  • CP7373-CE90-SF - 39.39mm
  • CP7373-OE90-SF - 40.19mm
  • CP7373-NE90-SF - 39.37mm
Clutch "Wear in" 0.75mm
Weight (Excluding Drive Plates) 3.34 Kg
Assembly Inertia (Excluding Drive Plates) 0.0218 Kg m²
Recommended Release Bearing
Drive Plate Options
  • New = 2.63mm (Nom.)
  • Worn = 2.22mm (Min.)

  • Back to back
  • Gear Driven Type
    • CP2822



Spare Parts:

 Main Pressure Plate CP3021-101
Intermediate Pressure Plate CP3592-106 (x2)
Wear Clips CP3913-103 (x6)
Brand AP Racing
Option SKU Barcode
Stepped Flywheel / 491 Nm (362 lbft) / Aluminium CP7373-NE90-SF
Stepped Flywheel / 798 Nm (588 lbft) / Aluminium CP7373-OE90-SF
Stepped Flywheel / 1272 Nm (938 lbft) / Aluminium CP7373-CE90-SF
